Design Features of the N Fire Protection Spiral Spray Nozzle

• Simplicity of design
• One-piece/no internal parts
• Clog-resistant
• Three standard pipe sizes—½", 1" and 1½"
• Male connection
• Factory Mutual, U.S. Coast Guard and Lloyd's Register approved models

Spray Characteristics of the N Fire Protection Nozzle

• Two spray cones—an outer, wide angle cone and a narrower inner cone—combine to give full cone effect

Spray pattern: Full Cone
Spray angles: 90° and 120° standard
Flow rates: 3.0 to 534 gpm (9.67 to 1720 L/min)

Fire Protection Approved
This BETE high-efficiency spiral was designed specifically with critical fire and explosion suppression applications in mind. These nozzles feature superior performance unequalled by traditional whirl nozzles.

Superior Performance Characteristics

• Sprays composed on droplets 30% to 50% smaller than conventional designs at equivalent pressures
• Extraordinarily large surface area of spray enhances evaporation and cooling
• Rugged, compact design
• Multiple concentric cone spray, unique to spiral pattern, maximizes contact

Superior Fire/Loss Prevention Applications

• Gas wellhead protection
• Safeguarding ship-borne cargo
• Storage tank protection
• Secondary explosion protection in explosive, dusty environments
• Mitigation of HF and other toxic gas releases
